Tri-band Wi-Fi SMD Ceramic Chip Antenna
AC10300-01
The AC10300-01 is an ultra-small high efficiency SMD ceramic chip antenna supporting WLAN/Wi-Fi 7 2400-2500MHz, 4900-7125 MHz.
The antenna is ideal for corner PCB mounting and is designed to also support MIMO applications using multiple antennas placed on the same PCB.
Categories: Embedded/Internal, SMD/Surface Mount, Tri-Band WiFi, Wi-Fi / Bluetooth
Tags: 1.6×0.8×0.8mm, 2.4 GHz Band, 5 GHz Band, 6 GHz Band, 802.11ac, 802.11ax, 802.11b, 802.11be, 802.11g, 802.11n, BLE, Bluetooth, Ceramic, Chip, IEEE 802.15.4, ISM, Linear Polarization, Omnidirectional, Passive, Solder, Wi-Fi, WiFi 4, WiFi 5, WiFi 6, WiFi 6E, WiFi 7, WLAN, ZigBee
Features
- Compact high efficiency antenna for corner PCB mount
- Low profile (< 0.8mm) SMD component for ease of integration
- Surface mount device suitable for automated assembly (SMT process)
- Supplied on tape & reel
- Ideal for MIMO systems 2×2, 4×4, 8×8.
- Ideal for smaller wearable designs
- RoHS and REACH compliant
