Low Profile SMD Ceramic Chip Antenna for GNSS Applications
AC30157-01
The AC30157-01 is an ultra-small high efficiency SMD ceramic chip antenna supporting GPS L1 (1.575GHz) and GLONASS G1 (1.601GHz) bands
The antenna is ideal for edge PCB mounting and is optimized for GNSS applications: Asset Trackers, Telematics, OBD II, Tablets and Handheld Devices.
Categories: Embedded/Internal, GNSS/Navigation, GPS / GNSS, SMD/Surface Mount
Tags: 1.6×0.8×0.8mm, Beidou, Ceramic, Chip, Compass, Galileo, GLONASS, GPS, Linear Polarization, Omnidirectional, Passive, QZSS, Solder
Features
- Compact high efficiency antenna (>75% in small form factor)
- Low profile (< 0.8mm) SMD component for ease of integration
- Surface mount device suitable for automated assembly (SMT process)
- Supplied on tape & reel
- Clean resonance with no unwanted out of band response
- Ideal for smaller wearable designs
- RoHS and REACH compliant
